MEDIALIGN

Power supply: 110V–220V AC
Operating temperature: 0–40°C
Operating humidity: 15%–80% non-condensing
Enclosure: Ergonomic aluminum and steel chassis

Freestanding Base Models:
155–(H)1961 x (W)1263 x (D) 720.3
255–(H)1961 x (W) 2526x (D) 720.3
170–(H)2018 x (W)1616 x (D) 742
270–(H)2018 x (W)3268 x (D)742
Slimline Base Models:
155–(H)1961 x (W)1263 x (D) 194
255–(H)1961 x (W) 2526x (D) 194
170–(H)2018 x (W)1616 x (D) 194.7
270–(H)2018 x (W)3268 x (D)194.7

Freestanding Models:
155–96.8 kg
255–216.8 kg
170–153 kg
270–284 kg
Slimline Models:
155–80.3 kg
255–169.8 kg
170–130 kg
270–240 kg
Regulatory compliance: UL/cUL
Power Inlet: 110V–220V AC circuit breaker protected to 10A

Diagonal screen size: 55" or 70"
Display type: Edge-lit LED display
Maximum resolution: 1920x1080p
Contrast ratio:
55"– 1000:1
70"–4000:1
Diagonal Screen Size:
55"–1387.80mm (54.64in)
70"–1777.74 (69.99in)
Power:
55"–75w per screen
70"–300w per screen
Viewing angle: +/- 178 degrees
Brightness:
55"–450 cd/m²
70"–350 cd/m²

Frequency response: 90-20kHz
THD at nominal output: < 1%
Woofer amplifier power: 17.5W, 1%THD; 25W, <10% THD (with 12V supply coltage)
Tweeter amplifier power: 15W, <1%THD
Power: 10-24Vdc (12Vdc nominal).
Peak current: 3A
No-signal input current: 0.3A
External power supply (provided):
Input: 100-240VAC, 50-60Hz 1.2A 12Vdc
Output: 12Vdc at 1.2A

Camera type: 1/2.33" CMOS
H/V Resolution: 1920 x 1080
Output: SMPTE 296M 1280 x 720p60, SMPTE 274M 1920 x 1080p, 60/50
Lens focal length: f=3.76–37.6mm
Zoom: 4x optical (black), 10x/12x (silver) optical/digital
Focus: Auto
Horizontal field of view: 65°, 85° with wide angle lens
Vertical field of view: 39°
Min. illumination: 50 lux
Exposure: Auto-iris, AGC
SNR: 50 db
Pan range: +/-100°
Tilt range: +20/-30°
I/O: Mini-HDCI—Hirose DH60-37P
IR detectors: Yes
Power consumption: 12v @ <2A power
Dimensions: 218 x 138 x 118 mm

Connections
1x HDCI (Out to Polycom RealPresence Group Series)
1x HDCI to Mini-HDCI
USB for local upgrades
Power
Camera Characteristics: Horizontal field of view 80 degrees and vertical manual tilt
Operating temperature: 0–40°C
Operating humidity: 15–80%
Non-operating temperature: -40–70°C
Non-operating humidity (noncondensing): 5–95%
Maximum Altitude: 10,000 ft
Electrical: Auto sensing power supply
Typical operating voltage/power: 22VA typical @ 120V @ 60Hz. 26VA @ 230V @ 50/60Hz
Typical BTU/h: 106 BTU/h
Physical size: 11.3" H x 1.2" W x 4.8" D
Physical weight: 1.93 lb

Connections
1x Mini-HDCI out to video system
2x USB 2.0
1x 3.5mm stereo line-in
1x HDMI in
1x HDMI out
Electrical: Auto sensing power supply
Typical operating voltage/power
60VA @ 120V @ 50Hz @ .49 PF
60VA @ 120V @ 60Hz @ .49 PF
74VA @ 200V @ 50Hz @ .40 PF
73VA @ 200V @ 60Hz @ .40 PF
87VA @ 260V @ 50Hz @ .34 PF
86VA @ 260V @ 60Hz @ .36 PF

Video input
1 x HDCI
1 x HDMI 1.3
1 x VGA
Video out: 2 x HDMI 1.3
People video resolution
1080p, 60 fps from 1740 Kbps
1080p, 30 fps from 1024 Kbps
720p, 60 fps from 832 Kbps
720p, 30 fps from 512 Kbps
4SIF/4CIF, 60 fps from 512 Kbps
4SIF/4CIF, 30 fps from 128 Kbps
SIF (352 x 240), CIF (352 x 288) from 64 kbps
QSIF (176 x 120), QCIF (176 x 144) from 64 kbps
w288p from 128 Kbps
w448 from 384 Kbps
w576p from 512 Kbps
Content video resolution (Input)
HD (1920 x 1080i), HD (1920 x 1080p)
WSXGA+ (1680 x 1050)
SXGA (1280 x 1024)
WXGA (1280 x 768)
HD (1280 x720p), XGA (1024 x 768)
SVGA (800 x 600)
Content video resolution (Output)
WUXGA (1920 x 1200)
HD (1920 x 1080)
WSXGA+ (1680 x 1050)
SXGA+ (1400 x 1050)
SXGA (1280 x 1024)
HD (1280 x 720)
XGA (1024 x 768)
VGA (640 x 480)
Content frame rate: 5–60 fps (up to 1080p resolution at 60 fps)
Content Sharing:
People+Content™, People+Content™ IP, Pano App and Pano (non-touch capabilities)
Audio input
1 x RealPresence Group Series microphone array input port (supporting a total of 4 microphone arrays)
1 x HDCI (camera)
1 x HDMI
1 x 3.5 mm stereo line-in
Audio output
1 x HDMI
1 x 3.5 mm stereo line-out
Other interfaces
2 x USB 2.0
1 x RS-232, 8-pin mini-DIN
Audio standards and protocols
22 kHz bandwidth with Polycom® Siren™ 22 technology, AAC-LD (TIP calls)
14 kHz bandwidth with Polycom Siren 14 technology, G.722.1 Annex C
7 kHz bandwidth with G.722, G.722.1
3.4 kHz bandwidth with G.711, G.728, G.729A
Polycom® Constant Clarity™ technology
Automatic gain control
Automatic noise suppression
Keyboard noise reduction
Polycom NoiseBlock technology
Polycom Acoustic Fence
Live music mode
Instant adaptation echo cancellation
Audio error concealment
Siren™ Lost Packet Recovery (LPR) technology
StereoSurround technology
Other supported standards
H224/H.281, H.323 Annex Q, H.225, H.245, H.241, H.239, H.243, H.460
BFCP (RFC 4582)
TIP
Network
IPv4 and IPv6 support
1 x 10/100/1G Ethernet
Auto-MDIX
H.323 and/or SIP up to 6 Mbps
Polycom Siren Lost Packet Recovery (LPR) technology

Display: 10.1-inch screen
Aspect ratio: 16 x 10
Resolution: WXGA (1280 x 800)
Viewing angle: > = 178 degrees
Positioning/placing angle: 30 degrees/65 degrees
Electrical
Power Over Ethernet (PoE), Compatible with IEEE 802.3af type 1
Low-power sleep mode
Physical dimensions: 252 x 175.8 x 11.25 mm (no stand)
Connections
Micro-B USB 2.0 OTG (Supports a USB connection to a PC for content sharing)
Type A USB 2.0 (Supports software updates)
Mechanical locking mechanism: Kensington lock
Glass: Scratch-resistant and oleophobic
Weight: 1 Kg (approximate)
Operating Temperature: 0ºC to 40ºC
Non-operating Temperature: -20ºC to 70ºC
Operating Altitude: 0 to 16,405 ft (~5000 meter) ASL
Non-operating Altitude: 0 to 50000 ft ASL
