EDUCART 500

55” LED flat panel

H.261, H.263, H.264 AVC, H.264 High Profile, H.264 SVC, RTV
H.239/People+Content™
H.263 & H.264 video error concealment

1080p, 60 fps from 1740 Kbps
1080p, 30 fps from 1024 Kbps
720p, 60 fps from 832 Kbps
720p, 30 fps from 512 Kbps
4SIF/4CIF, 60 fps from 512 Kbps
4SIF/4CIF, 30 fps from 128 Kbps
SIF (352 x 240), CIF (352 x 288) from 64 kbps
QSIF (176 x 120), QCIF (176 x 144) from 64 kbps
w288p from 128 Kbps
w448 from 384 Kbps
w576p from 512 Kbps

1 x EagleEye HD camera (HDCI)
1 x HDMI 1.3
1 x VGA

2 x HDMI 1.3

Input:
WUXGA (1920 x 1200)
HD (1920 x 1080i), HD (1920 x 1080p
WSXGA+ (1680 x 1050)
UXGA (1600 x 1200)
SXGA (1280 x 1024)
WXGA (1280 x 768)
HD (1280 x720p), XGA (1024 x 768)
SVGA (800 x 600)

StereoSurround™ technology
22 kHz bandwidth with Siren™ 22 technology
14 kHz bandwidth with Siren™ 14 technology, G.722.1 Annex C
7 kHz bandwidth with G.722, G.722.1
3.4 kHz bandwidth with G.711, G.728, G.729A
Automatic gain control
Automatic noise suppression
Instant adaptation echo cancellation
Audio error concealment
Keyboard noise reduction
Live MusicMode™ technology
Other ITU-supported standards
H.224/H.281 far-end camera control
H.323 Annex Q far-end camera control
H.225, H.245, H.241
H.239 dual stream
H.460 NAT/firewall traversal

Structural support for the included 55” display
Adjustable height to accommodate user need, center of display height: 46”, 50” or 54”
2 x powered speakers (25W LF & 16W HF per speaker) with integrated high efficiency digital amplifier
Sturdy side handles allow cart to be safely and easily moved and maneuvered
4” locking heavy duty swivel casters
Integral cable runs from display top to base for hiding unsightly cables
Integrated basket with cover to hold microphone/cable, IR remote
Rear cover to neatly hide codec, power supply, and power bar behind display

1080p license, providing up to 1080p60 for people and content
Multipoint license for up to 6 sites (SDCP), or 4 sites (HDCP)

49”W x 74”H x 33.25”D (with display and camera)

144 lbs
